RoHS DGW40N65CTL COMPLIANT IGBT Modules V 650 V CEI 40 A CV I = A 1.80 V CE(SAT) C 40 Applications Inverter for motor drive AC and DC servo drive amplifier Circuit Uninterruptible power supply Motion/servo control Features High breakdown voltage to 650V for improved reliability Maximum junction temperature 175 Positive temperature coefficient Including fast & soft recovery anti-parallel FWD High short circuit capability(5us) Maximum Ratings Parameter Symbol Value Unit V 650 V CECollector-Emitter Breakdown Voltage DC Collector Current, limited by T jmaxT = 25C 80 CI A C 40 T = 100C CDiode Forward Current, limited by T jmaxT = 25C C 80 I A F 40 T = 100C CVGE 20 V Continuous Gate-Emitter Voltage VGE 30 V Transient Gate-Emitter Voltag
