Скачать даташит для dgw50n65ctl1:
RoHS COMPLIANT DGW50N65CTL1 IGBT Discrete V 650 V CEI 50 A CVCE(SAT) 1.60 V I = AC 50 Applications High frequency switching application Resonant converters Uninterruptible power supply Circuit Welding converters Features High speed smooth switching device for hard & soft switching Maximum junction temperature 175 Positive temperature coefficient High ruggedness, temperature stable Pb-free lead plating; RoHS compliant Maximum Ratings Parameter Symbol Value Unit VCE 650 V Collector-Emitter Breakdown Voltage DC Collector Current, limited by Tjmax IC 85 TC=25C value limited by bondwire A 60 TC= 100C Diode Forward Current, limited by Tjmax IF 85 TC= 25C value limited by bondwire A 60 TC= 100C VGE 20 V Continuous Gate-Emitter Voltage Transient Ga
