RoHS DGW75N65CTL1 COMPLIANT IGBT Discrete V 650 V CEI 75 A CVCE(SAT) 1.65 V I = AC 75 Applications High frequency switching application Resonant converters Uninterruptible power supply Circuit Welding converters Features High speed smooth switching device for hard & soft switching Maximum junction temperature 175 Positive temperature coefficient High ruggedness, temperature stable Pb-free lead plating; RoHS compliant Maximum Ratings Parameter Symbol Value Unit VCE 650 V Collector-Emitter Breakdown Voltage DC Collector Current, limited by Tjmax 85 TC= 25C value limited by bondwire IC A 80 TC= 100C Diode Forward Current, limited by Tjmax 85 TC= 25C value limited by bondwire IF A 80 TC= 100C VGE 20 Continuous Gate-Emitter Voltage V Transient Gate-
