SMD Type MOSFETN-Channel MOSFETDMZ6005E (KMZ6005E)SOT-23Unit: mm+0.12.9 -0.1+0.10.4-0.1 Features3 VDS (V) = 600V ID = 20mA RDS(ON) 700m (VGS = 0 V)1 2+0.1+0.050.95 -0.1 Fast Switching Speed 0.1 -0.01+0.11.9 -0.1 RoHS Compliant Halogen-free available1. Gate2. Source3. Drain Absolute Maximum Ratings Ta = 25Parameter Symbol Rating Unit Drain-Source Voltage VDS 600V Drain-Gate Voltage[ VDG 600 Gate-Source Voltage VGS 20 Continuous Drain Current ID 20mA Pulsed Drain Current IDM 80 Power Dissipation PD 500 mW Thermal Resistance.Junction- to-Ambient RthJA 250 /W Soldering Temperature TL 300 Junction Temperature TJ 150 Storage Temperature Range Tstg -55 to 1501www.kexin.com.cn0.4+0.1+0.12.4-0.11.3-0.10.55+0.10.97-0.1+0.10-0.10.38-0.1
