IGBT - Field Stop600 V, 60 AFGH60N60SFDTU-F085DescriptionUsing Novel Field Stop IGBT Technology, ON Semiconductorsnew series of Field Stop IGBTs offer the optimum performance forwww.onsemi.comAutomotive Chargers, Inverter, and other applications where lowconduction and switching losses are essential.CFeatures High Current Capability Low Saturation Voltage: VCE(sat) = 2.2 V @ IC = 60 AG High Input Impedance Fast SwitchingE Qualified to Automotive Requirements of AEC-Q101 This Device is Pb-Free and is RoHS CompliantECGGApplications Automotive chargers, Converters, High Voltage AuxiliariesCOLLECTOR Inverters, PFC, UPS(FLANGE)TO-247-3LDCASE 340CKMARKING DIAGRAM$Y&Z&3&KFGH60N60SFDTU$Y = ON Semiconductor Logo&Z = Assembly Plant Code&3 = Numeric Date Code&K = Lot CodeFGH60N60SFDTU = Specifi
