Скачать даташит для fgh60n60smd:

March 2011FGH60N60SMDtm600V, 60A Field Stop IGBTFeatures General Description Maximum Junction Temperature : TJ =175oC Using Novel Field Stop IGBT Technology, Fairchilds new series of Field Stop IGBTs offer the optimum performance for Solar Positive Temperaure Co-efficient for easy parallel operatingInverter, UPS, SMPS, IH and PFC applications where low con- High current capabilityduction and switching losses are essential. Low saturation voltage: VCE(sat) =1.9V(Typ.) @ IC = 60A High input impedance Fast switching Tighten Parameter Distribution RoHS compliantApplications Solar Inverter, UPS, SMPS, PFC Induction HeatingECCGGCOLLECTOR(FLANGE) EAbsolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 600 VVGES Gate to Emitter Voltage 20 VCollector Current @ TC
