October 2008FGP20N60UFDtm600V, 20A Field Stop IGBTFeatures General Description High current capability Using Novel Field Stop IGBT Technology, Fairchilds new seriesof Field Stop IGBTs offer the optimum performance for Induction Low saturation voltage: VCE(sat) =1.8V @ IC = 20AHeating, UPS, SMPS and PFC applications where low conduc- High input impedancetion and switching losses are essential. Fast switching RoHS compliantApplications Induction Heating, UPS, SMPS, PFCCGTO-22011.Gate 2.Collector 3.Emitter EAbsolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 600 VVGES Gate to Emitter Voltage 20 VCollector Current @ TC = 25oC40 AICCollector Current @ TC = 100oC20 AICM (1) Pulsed Collector Current 60 A@ TC = 25oC Maximum Power Dissipation @ TC = 25oC165 WPDMaximum Po
