TIGER ELECTRONIC CO.,LTD500V N-Channel MOSFETFQD5N50DESCRIPTIONThese N-Channel enhancement mode power field effecttransistors are produced using Fairchilds proprietary,planar stripe, DMOS technology.This advanced technology has been especially tailored tominimize on-state resistance, provide superior switchingperformance, and withstand high energy pulse in theavalanche and commutation mode. These devices are wellsuited for high efficiency switch mode power supply.OABSOLUTE MAXIMUM RATINGS( Ta = 25 C)Parameter Value UnitSymbolDrain-Source Voltage V 500 VDSSDrain Current - Continuous I 3.5 ADDrain Current - Pulsed I 14 ADMGate-Source Voltage V 30 VGSSPower Dissipation P 50 WDoMax. Operating Junction Temperature T 150 CjTO-252oStorage Temperature T -55~150 CstgOELECTRICAL CHARACTERISTICS( Ta = 25 C)Parameter Sym
