FTP10N40/FTA10N40400V N-Channel MOSFET BVDSS RDS(ON) (Max.) ID General Features Low ON Resistance 400V 0.50 10A Low Gate Charge (typical 34nC) Fast Switching 100% Avalanche Tested RoHS Compliant/Lead Free Applications High Efficiency SMPS Adaptor/Charger LCD Panel Power Switching application Ordering Information Part Number Package Marking FTP10N40 TO-220 FTP10N40FTA10N40 TO-220F FTA10N40Absolute Maximum Ratings TC=25 unless otherwise specified Symbol Parameter FTP10N40 FTA10N40 UnitVDSS Drain-to-Source Voltage[1] 400 VID Continuous Drain Current 10 10* ID@100 Continuous Drain Current Figure 3 A IDM Pulsed Drain Current, VGS@10V[2] Figure 6Power Dissipation 125 31 W PD Derating Factor above 25 1.0 0.25 W/ VGS Gate-to-Source Voltage 30 VSingle Pulse Avalanche EAS 360 mJEnergy L=7.2mH, ID=10A
