IKW50N60T TrenchStop Series q Low Loss DuoPack : IGBT in Trench and Fieldstop technology with soft, fast recovery anti-parallel EmCon HE diode C Very low VCE(sat) 1.5 V (typ.) Maximum Junction Temperature 175 C Short circuit withstand time 5s GE Designed for : - Frequency Converters - Uninterrupted Power Supply Trench and Fieldstop technology for 600 V applications offers : - very tight parameter distribution P-TO-247-3-1 (TO-220AC) - high ruggedness, temperature stable behavior - very high switching speed - low VCE(sat) Positive temperature coefficient in VCE(sat) Low EMI Low Gate Charge Very soft, fast recovery anti-parallel EmCon HE diode Complete product spectrum and PSpice Models : http://www.infineon.com/igbt/ Type VCE IC VCE(sat),Tj=25C Tj,max Marking Code Package Ordering Code
