PD - 94494AIRF1503SIRF1503LTypical ApplicationsHEXFET Power MOSFET 14V Automotive Electrical SystemsD 14V Electronic Power SteeringVDSS = 30VBenefits Advanced Process TechnologyRDS(on) = 3.3m Ultra Low On-ResistanceG 175C Operating Temperature Fast Switching ID = 75AS Repetitive Avalanche Allowed up to TjmaxDescriptionSpecifically designed for Automotive applications, this Stripe Planardesign of HEXFET Power MOSFETs utilizes the lastest processingtechniques to achieve extremely low on-resistance per silicon area.Additional features of this HEXFET power MOSFET are a 175Cjunction operating temperature, fast switching speed and improvedrepetitive avalanche rating. These benefits combine to make thisD2Pak TO-262design an extremely efficient and reliable device for use in AutomotiveIRF1503S IRF1503Lappl
