PD - 95432AIRF1503SPbFIRF1503LPbFTypical ApplicationsHEXFET Power MOSFET Industrial Motor DriveDVDSS = 30VBenefitsl Advanced Process Technologyl Ultra Low On-Resistance RDS(on) = 3.3mGl 175C Operating Temperaturel Fast SwitchingID = 75Al Repetitive Avalanche Allowed up to TjmaxSDescriptionThis Stripe Planar design of HEXFET Power MOSFETsutilizes the lastest processing techniques to achieveextremely low on-resistance per silicon area. Additionalfeatures of this HEXFET power MOSFET are a 175Cjunction operating temperature, fast switching speed andimproved repetitive avalanche rating. These benefitscombine to make this design an extremely efficient andD2Pak TO-262reliable device for use in a wide variety of applications.IRF1503SPbF IRF1503LPbFAbsolute Maximum RatingsParameter Max. UnitsID @ TC = 25C Continuous Drain
