PD - 94613ASMPS IGBT IRGB20B60PD1WARP2 SERIES IGBT WITHULTRAFAST SOFT RECOVERY DIODEC VCES = 600VApplicationsVCE(on) typ. = 2.05V Telecom and Server SMPS@ VGE = 15V IC = 13.0A PFC and ZVS SMPS Circuits Uninterruptable Power SuppliesEquivalent MOSFET Consumer Electronics Power SuppliesGParameters Features RCE(on) typ. = 158mE NPT Technology, Positive Temperature CoefficientID (FET equivalent) = 20A Lower VCE(SAT) n-channel Lower Parasitic Capacitances Minimal Tail Current HEXFRED Ultra Fast Soft-Recovery Co-Pack Diode Tighter Distribution of Parameters Higher ReliabilityBenefitsEC Parallel Operation for Higher Current ApplicationsG Lower Conduction Losses and Switching LossesTO-220AB Higher Switching Frequency up to 150kHzAbsolute Maximum RatingsParameter Max. UnitsVCES C
