Скачать даташит для irgps40b120ud:

PD- 94240AIRGPS40B120UDINSULATED GATE BIPOLAR TRANSISTOR WITHULTRAFAST SOFT RECOVERY DIODE UltraFast Co-Pack IGBTCVCES = 1200VFeatures Non Punch Through IGBT Technology. Low Diode VF.VCE(on) typ. = 3.12V 10s Short Circuit Capability. Square RBSOA.G@ VGE = 15V, Ultrasoft Diode Reverse Recovery Characteristics. Positive VCE (on) Temperature Coefficient.E Super-247 Package.ICE = 40A, Tj=25CN-channelBenefits Benchmark Efficiency for Motor Control. Rugged Transient Performance. Low EMI. Significantly Less Snubber Required Excellent Current Sharing in Parallel Operation.Super-247Absolute Maximum Ratings Parameter Max. UnitsVCES Collector-to-Emitter Voltage 1200 VIC @ TC = 25C Continuous Collector Current 80IC @ TC = 100C Continuous Collector Current 40ICM Pulsed Collector Current 1
