Advance Technical InformationIXGH 35N120B VCES = 1200 VHiPerFASTTM IGBTIXGT 35N120B IC2 = 70 AVCE(sat) = 3.3 Vtfi(typ) = 160 nsSymbol Test Conditions Maximum Ratings TO-268(IXGT)VCES TJ = 25C to 150C 1200 VVCGR TJ = 25C to 150C; RGE = 1 MW 1200 VGEVGES Continuous 20 VC (TAB)VGEM Transient 30 VIC25 TC = 25C70 ATO-247 AD (IXGH)IC90 TC = 90C35 AICM TC = 25C, 1 ms 140 ASSOA VGE= 15 V, TVJ = 125C, RG = 5 W ICM = 90 A(RBSOA) Clamped inductive load @ 0.8 VCES C (TAB)GCPC TC = 25C 300 W ETJ -55 ... +150 CG = Gate, C = Collector,TJM 150 CE = Emitter, TAB = CollectorTstg -55 ... +150 CMaximum Lead temperature for soldering 300 C1.6 mm (0.062 in.) from case for 10 sMaximum Tab temperature for soldering SMD devices for 10 s 260 CFeatures International standard packagesMd Mounting torque (M3) 1.1
