KC5344S NPN Silicon Transistor Description Audio power amplifier application PIN Connection Features High hFE : hFE=100~320 Complementary pair with KA1981S Ordering Information Type NO. Marking Package Code FA KC5344S SOT-23 Device Code HFE Rank Year& Week Code Dalian Absolute maximum ratings Ta=25C Characteristic Symbol Ratings Unit Collector-Base voltage VCBO 30 V Collector-Emitter voltage VCEO 35 V Emitter-Base voltage VEBO 5 V Collector current IC 800 mA Collector dissipation PC* 350 mW Junction temperature Tj 150 C Storage temperature range Tstg -55~150 C * Package mounted on 99.5% alumina 1080.6mm Electrical Characteristics Ta=25C Characteristic Symbol Test Condition Min. Typ. Max. Unit Collector-Base breakdown voltage BVCBO IC=100A, IE=0 35 - - V Collector Emitt
