KS8050L NPN Silicon Transistor Descriptions PIN Connection High current application Features Complementary pair with KS8550L Ordering Information Type NO. Marking Package Code KK KS8050L SOT-23 Device Code HFE Grade Year& Week Code AUK Dalian SOT-23 Absolute maximum ratings Ta=25C Characteristic Symbol Ratings Unit Collector-Base voltage VCBO 40 V Collector-Emitter voltage VCEO 25 V Emitter-base voltage VEBO 6 V Collector current IC 1500 mA Collector dissipation PC 350 mW Junction temperature Tj 150 C Storage temperature range Tstg -55~150 C Electrical Characteristics Ta=25C Characteristic Symbol Test Condition Min. Typ. Max. Unit Collector-Base breakdown voltage BVCBO IC=100uA, IE=0 40 - - V Collector-Emitter breakdown voltage BVCEO IC=2mA, IB=0 25 - - V Emitter-Base breakdown vo
