KSE13006/13007High Voltage Switch Mode Application High Speed Switching Suitable for Switching Regulator and Motor ControlTO-22011.Base 2.Collector 3.EmitterNPN Silicon TransistorAbsolute Maximum Ratings TC=25C unless otherwise notedSymbol Parameter Value Units VCBO Collector-Base Voltage : KSE13006 600 V : KSE13007 700 V VCEO Collector-Emitter Voltage : KSE13006 300 V : KSE13007 400 V VEBO Emitter- Base Voltage 9 V IC Collector Current (DC) 8 AICP Collector Current (Pulse) 16 AIB Base Current 4 A PC Collector Dissipation (TC=25C) 80 W TJ Junction Temperature 150 C TSTG Storage Temperature - 65 ~ 150 CElectrical Characteristics TC=25C unless otherwise notedSymbol Parameter Test Condition Min. Typ. Max. Units BVCEO Collector- Emitter Breakdown Voltage : KSE13006 IC = 10mA, IB = 0 300 V: KSE13007 400 V IEBO Emitter Cut-
