KSH44H11 NPN EPITAXIAL SILICON TRANSISTORGENERAL PURPOSE POWER AND SWITCHINGD-PAKSUCH AS OUTPUT OR DRIVER STAGES INAPPLICATIONS D-PACK FOR SURFACEMOUNT APPLICATIONS Load Formed for Surface Mount Application(No Suffix) Straight Lead (I.PACK, - I Suffix) 1 Electrically Similar to Popular KSE44H Fast Switching Speeds Low Collector Emitter Saturation Voltage1. Base 2. Collector 3. EmitterABSOLUTE MAXIMUM RATINGS I-PAKCharacteristic Symbol Rating Unit Collector Emitter Voltage VCEO 80 V Emitter Base Voltage VEBO 5 V Collector Current (DC) IC 8 A1 Collector Current (Pulse) IC 16 A Collector Dissipation ( TC=25 ) PC 20 WPC 1.75 W Collector Dissipation (TA=25 ) 1. Base 2. Collector 3. Emitter Junction Temperature TJ 150 Storage Temperature TSTG -65 ~ 150 ELECTRICAL CHARACTERISTICS (Tc =25 )Characteristic Symbol Test Condit
