KSH44H11General Purpose Power and Switching Such as Output or Driver Stages in Applications D-PAK for Surface Mount Applications Lead Formed for Surface Mount Application (No Suffix)D-PAK I-PAK11 Straight Lead (I-PAK, - I Suffix) Electrically Similar to Popular KSE44H1.Base 2.Collector 3.Emitter Fast Switching Speeds Low Collector Emitter Saturation VoltageNPN Epitaxial Silicon TransistorAbsolute Maximum Ratings TC=25C unless otherwise notedSymbol Parameter Value Units VCEO Collector-Emitter Voltage 80 V VEBO Emitter-Base Voltage 5 V IC Collector Current (DC) 8 A ICP Collector-Current (Pulse) 16 APC Collector Dissipation (TC=25C) 20 W Collector Dissipation (Ta=25C) 1.75 W TJ Junction Temperature 150 C TSTG Storage Temperature - 65 ~ 150 CElectrical Characteristics TC=25C unless otherwise notedSymbol Param
