LESHAN RADIO COMPANY, LTD.General Purpose TransistorLMBT2222ATT1GNPN SiliconS-LMBT2222ATT1GThese transistors are designed for general purpose amplifierapplications. They are housed in the SC-89 package whichis designed for low power surface mount applications.Featurescompliance with RoHS requirements. We declare that the material of product S- Prefix for Automotive and Other Applications Requiring Unique SiteSC-89and Control Change Requirements; AEC-Q101 Qualified and PPAP Capable.ORDERING INFORMATIONCOLLECTORDevice Maring Shipping3LMBT2222ATT1G 1P3000 / Tape & ReelS-LMBT2222ATT1G 1P1LMBT2222ATT3G 1P10000 / Tape & ReelBASES-LMBT2222ATT3G 1P2EMITTERMAXIMUM RATINGS (TA = 25C)Rating Symbol Max UnitCollector-Emitter Voltage VCEO 40 VdcCollector-Base Voltage VCBO 75 VdcMARKING DIAGRAMEmitter-Base Voltage VEBO 6
