LESHAN RADIO COMPANY, LTD.General Purpose TransistorsNPN SiliconThese transistors are designed for generalpurpose amplifier applications. They are LMBT2222AWT1Ghoused in the SOT323/SC70 package whichS-LMBT2222AWT1Gis designed for low power surface mountapplications.We declare that the material of product 3compliance with RoHS requirements.S- Prefix for Automotive and Other Applications Requiring Unique Siteand Control Change Requirements; AEC-Q101 Qualified and PPAP Capable. 12MAXIMUM RATINGSCASE 41902, STYLE 3SOT323 /SC 70Rating Symbol Value UnitCollectorEmitter Voltage V CEO 40 VdcCollectorBase Voltage V CBO 75 Vdc3EmitterBase Voltage V EBO 6.0 Vdc COLLECTORCollector Current Continuous I C 600 mAdc1BASETHERMAL CHARACTERISTICS2EMITTERCharacteristic Symbol Max UnitTotal Device Dissipation FR 5
