UNISONIC TECHNOLOGIES CO., LTD MJE13003K NPN SILICON TRANSISTOR NPN SILICON POWER TRANSISTOR DESCRIPTION These devices are designed for highvoltage, highspeed power switching inductive circuits where fall time is critical. They are particularly suited for 115 and 220V SWITCHMODE. FEATURES * Reverse biased SOA with inductive load @ Tc=100C * Inductive switching matrix 0.5 ~ 1.5 Amp, 25 and 100C Typical tc = 290ns @ 1A, 100C. * 700V blocking capability APPLICATIONS * Switching regulators, inverters * Motor controls * Solenoid/relay drivers * Deflection circuits ORDERING INFORMATION Ordering Number Pin Assignment Package PackingLead Free Halogen-Free 1 2 3MJE13003KL-x-x-T60-K MJE13003KG-x-x-T60-K TO-126 B C E BulkMJE13003KL-x-x-T6C-A-K MJE13003KG-x-x-T6C-A-K TO-126C E C B BulkMJE13003KL-x-x-T6C-F-K MJE13003KG-x-x-T6C-
