MJE13007GSWITCHMODEtNPN Bipolar Power TransistorFor Switching Power Supply ApplicationsThe MJE13007G is designed for high-voltage, high-speed powerhttp://onsemi.comswitching inductive circuits where fall time is critical. It is particularlysuited for 115 and 220 V SWITCHMODE applications such asSwitching Regulators, Inverters, Motor Controls, Solenoid/Relay POWER TRANSISTORdrivers and Deflection circuits.8.0 AMPERES400 VOLTS - 80 WATTSFeatures VCEO(sus) 400 V Reverse Bias SOA with Inductive Loads @ TC = 100C 700 V Blocking Capability SOA and Switching Applications Information Standard TO-220 These Devices are Pb-Free and are RoHS Compliant*MAXIMUM RATINGSRating Symbol Value UnitCollector-Emitter Sustaining Voltage VCEO 400 VdcTO-220ABCASE 221A-09Collector-Base Breakdown Voltage VCES 700 VdcSTYLE 1Emitter-Base Volt
