SEMICONDUCTOR MJE13007TECHNICAL DATA TRIPLE DIFFUSED NPN TRANSISTORSWITCHING REGULATOR APPLICATION.HIGH VOLTAGE SWITCHING APPLICATION.HIGH SPEED DC-DC CONVERTER APPLICATION.FEATURESExcellent Switching Times: ton=1.6 S(Max.), at IC=5AS(Max.), tf=0.7High Collector Voltage : VCBO=700V.MAXIMUM RATING (Ta=25)CHARACTERISTIC SYMBOL RATING UNITVCBOCollector-Base Voltage 700 VVCEOCollector-Emitter Voltage 400 VVEBOEmitter-Base Voltage 9 VICDC 8Collector Current AICPPulse 16IBBase Current 4 ACollector Power DissipationPC80 W(Tc=25)TjJunction Temperature 150Tstg -55150 Storage Temperature RangeELECTRICAL CHARACTERISTICS (Ta=25)CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNITIEBO VEB=9V, IC=0Emitter Cut-off Current - - 1 mAhFE(1) (Note) VCE=5V, IC=2A15 - 39DC Current GainhFE(2) VCE=
