Скачать даташит для mje13007:

MJE13007 SILICON NPN SWITCHING TRANSISTOR SGS-THOMSON PREFERRED SALESTYPE NPN TRANSISTOR HIGH CURRENT CAPABILITYAPPLICATIONS SWITCHING REGULATORS MOTOR CONTROLDESCRIPTION32The MJE13007 is a silicon multiepitaxial mesa1NPN power transistor mounted in Jedec TO-220plastic package.TO-220It is are inteded for use in motor control, switchingregulators etc.INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitVCEV Collector-Emitter Voltage (VBE = -1.5V) 700 VV Collector-Emitter Voltage (I = 0) 400 VCEO BVEBO Emitter-Base Voltage (IC = 0) 9 VIC Collector Current 8 AI Collector Peak Current 16 ACMI Base Current 4 ABI Base Peak Current 8 ABMIE Emitter Current 12 AIEM Emitter Peak Current 24 AoP Total Dissipation at T 25 C80 Wtot coTstg Storage Temperature -65 to 150 CoT Max. Operating
