MJE13007A SILICON NPN SWITCHING TRANSISTOR SGS-THOMSON PREFERRED SALESTYPE NPN TRANSISTOR HIGH CURRENT CAPABILITY APPLICATIONS SWITCHING REGULATORS MOTOR CONTROL DESCRIPTION 3The MJE13007A is silicon multiepitaxial mesa 21NPN power transistor mounted in Jedec TO-220plastic package.TO-220They are inteded for use in motor control,switching regulators etc.INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitVCEV Collector-Emitter Voltage (VBE = -1.5V) 850 VVCEO Collector-Emitter Voltage (IB = 0) 400 VVEBO Emitter-Base Voltage (IC = 0) 9 VI Collector Current 8 ACICM Collector Peak Current 16 AIB Base Current 4 AIBM Base Peak Current 8 AIE Emitter Current 12 AIEM Emitter Peak Current 24 AP Total Dissipation at T 25 oC80 Wtot coTstg Storage Temperature -65 to 150 CoT Max. Operating Junction
