MCCMicro Commercial ComponentsTM20736 Marilla Street ChatsworthMMBT2222AMicro Commercial ComponentsCA 91311Phone: (818) 701-4933Fax: (818) 701-4939Features Surface Mount SOT-23 Package Capable of 350mWatts of Power Dissipation, IC=600mANPN General Operating and Storage Junction Temperature: -55C to +150C Thermal resistance,Junction to Ambient:500oC/WPurpose Amplifier Epoxy meets UL 94 V-0 flammability rating Moisture Sensitivity Level 1 Marking:1P Lead Free Finish/RoHS Compliant("P"Suffix designates Compliant) Electrical Characteristics @ 25C Unless Otherwise Specified SOT-23ASymbol Parameter Min Max UnitsDOFF CHARACTERISTICSC V(BR)CEO Collector-Emitter Breakdown Voltage* 40 Vdc (IC=10mAdc, IB=0)BC V(BR)CBO Collector-Base Breakdown Voltage 75 Vdc (IC=10Adc, IE=0)B E V(BR)EBO Emitter-Ba
