MMBT2222ALP440V NPN SMALL SIGNAL SURFACE MOUNT TRANSISTOR Features Mechanical Data Low Collector-Emitter Saturation Voltage, VCE(sat) Case: X2-DFN1006-3 Case Material: Molded Plastic, "Green" Molding Compound. Ultra-Small Leadless Surface Mount Package UL Flammability Classification Rating 94V-0 Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2) Moisture Sensitivity: Level 1 per J-STD-020 Halogen and Antimony Free. Green Device (Note 3) Qualified to AEC-Q101 Standards for High Reliability Terminals: Finish NiPdAu over Copper leadframe. Solderable per MIL-STD-202, Method 208 e4 Weight: 0.0009 grams (Approximate) X2-DFN1006-3 CBBCEETop View Bottom View Device Symbol Device Schematic Ordering Information (Note 4) Product Marking Reel size (inches) Tape width (mm) Quantity per reel MMBT
