MMBT2222AT 40V NPN SMALL SIGNAL TRANSISTOR IN SOT523 Features Mechanical Data BVCEO > 40V Case: SOT523 Case Material: Molded Plastic. Green Molding Compound. IC = 600mA Collector Current UL Flammability Rating 94V-0 Epitaxial Planar Die Construction Moisture Sensitivity: Level 1 per J-STD-020 Ultra-Small Surface Mount Package Terminals: Finish - Matte Tin Plated Leads, Solderable per Complementary PNP Type: MMBT2907AT MIL-STD-202, Method 208 e3 Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2) Weight: 0.002 grams (Approximate) Halogen and Antimony Free. Green Device (Note 3) Qualified to AEC-Q101 Standards for High Reliability CSOT523 BEPin-out Top View Top View Device Symbol Ordering Information (Note 4) Product Status Compliance Marking Reel Size (inches) Tape Width
