MMBTSC2412 TRANSISTOR (NPN) FEATURES SOT-23 Low Cob ,Cob = 2.0 pF (Typ). 1BASE 2EMITTER 3COLLECTOR MARKING : BR MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value Units VCBO Collector-Base Voltage 60 V VCEO Collector-Emitter Voltage 50 V VEBO Emitter-Base Voltage 7 V IC Collector Current -Continuous 150 mA PC Collector Power Dissipation 200 mW TJ Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNITCollector-base breakdown voltage V(BR)CBO IC=50A, IE=0 60 V Collector-emitter breakdown voltage V(BR)CEO IC=1mA, IB=0 50 V Emitter-base breakdown voltage V(BR)EBO IE=50A, IC=0 7 V Collector cut-off current ICBO VCB=60V, IE=0 0.1 A Emitter cut-off current IEBO VEB=7V, IC=0 0.1
