Скачать даташит для mmg300d120b6tc:
MMG300D120B6TC1200V 300A IGBT ModuleDecember 2019 Version 01 RoHS CompliantPRODUCT FEATURES IGBT CHIP(Trench+Field Stop technology) VCE(sat) with positive temperature coefficient High short circuit capability Fast switching and short tail current Free wheeling diodes with fast and soft reverse recovery Low switching lossesAPPLICATIONS High frequency switching application Medical applications Motion/servo control UPS systemsIGBT-inverterABSOLUTE MAXIMUM RATINGS(T =25C unless otherwise specified)CSymbol Parameter/Test Conditions ValuesUnitVCES TJ=25 1200Collector Emitter VoltageVVGESGate Emitter Voltage 20TC=25, TJmax=175 438ICDC Collector CurrentTC=95, TJmax=175 300 AICMRepetitive Peak Collector Current tp=1ms 600Ptot TC=25, TJmax=175 1500 WPower Dissipation Per IGBT
