NCEP015NH30AGUhttp://www.ncepower.comNCE N-Channel Super Trench III Power MOSFETDescriptionThe NCEP015NH30AGU uses Super Trench III technologyGeneral Featuresthat is uniquely optimized to provide the most efficient highV =30V,I =180ADS Dfrequency switching performance. Both conduction and R =1.4m (typical) @ V =10VDS(ON) GSswitching power losses are minimized due to an extremely lowExcellent gate charge x R product(FOM)DS(on)combination of R and Q . This device is ideal forDS(ON) g Very low on-resistance RDS(on)high-frequency switching and synchronous rectification.150C operating temperatureApplication Pb-free lead plating100% UIS TESTED!DC/DC Converter100% Vds TESTED!Ideal for high-frequency switching and synchronousrectificationPDFN 5X6-8LTop View Schematic DiagramBottom ViewPackage Marking and Order
