NCEP015NH30GUhttp://www.ncepower.comNCE N-Channel Super Trench III Power MOSFETDescriptionGeneral FeaturesThe NCEP015NH30GU uses Super Trench III technologyV =30V,I =189ADS Dthat is uniquely optimized to provide the most efficient highR =1.25m (typical) @ V =10VDS(ON) GSfrequency switching performance. Both conduction andR =1.7m (typical) @ V =4.5VDS(ON) GSswitching power losses are minimized due to an extremely lowExcellent gate charge x R product(FOM)DS(on)combination of R and Q . This device is ideal forDS(ON) gVery low on-resistance RDS(on)high-frequency switching and synchronous rectification.150C operating temperatureApplication Pb-free lead platingDC/DC Converter100% UIS TESTED!Ideal for high-frequency switching and synchronous100% Vds TESTED!rectificationPDFN 5X6-8LTop View Schematic Dia
