MBT2222ADW1,NSVBT2222ADW1General Purpose TransistorNPN Siliconhttp://onsemi.comFeatures Moisture Sensitivity Level: 1 NSV Prefix for Automotive and Other Applications Requiring(3) (2) (1)Unique Site and Control Change Requirements; AEC-Q101Qualified and PPAP CapableQ1 Q2 These Devices are Pb-Free, Halogen Free/BFR Free and are RoHSCompliant(4) (5) (6)MAXIMUM RATINGSRating Symbol Value UnitCollector-Emitter Voltage VCEO 40 VdcCollector-Base Voltage VCBO 75 Vdc1Emitter-Base Voltage VEBO 6.0 VdcSC-88/SC70-6/SOT-363Collector Current - Continuous IC 600 mAdc CASE 419BSTYLE 1Electrostatic Discharge ESD HBM Class 2MM Class BMARKING DIAGRAMTHERMAL CHARACTERISTICSCharacteristic Symbol Max Unit6Total Package Dissipation (Note 1), PD 150 mW1P M GTA = 25CGThermal Resistance, RqJA 833 C/W1Junction-to-AmbientJunc
