MMBT2222ATT1G,NSVMMBT2222ATT1GGeneral Purpose TransistorNPN SiliconThese transistors are designed for general purpose amplifierhttp://onsemi.comapplications. They are housed in the SOT-416/SC-75 package whichis designed for low power surface mount applications.COLLECTOR3Features NSV Prefix for Automotive and Other Applications Requiring1Unique Site and Control Change Requirements; AEC-Q101 QualifiedBASEand PPAP Capable These Devices are Pb-Free, Halogen Free/BFR Free and are RoHS2EMITTERCompliant3CASE 463SOT-416/SC-75MAXIMUM RATINGS (TA = 25C)2STYLE 11Rating Symbol Max UnitCollector-Emitter Voltage VCEO 40 VdcMARKING DIAGRAMCollector-Base Voltage VCBO 75 VdcEmitter-Base Voltage VEBO 6.0 VdcCollector Current - Continuous IC 600 mAdc 1P M GGTHERMAL CHARACTERISTICS1Characteristic Symbol Max Unit1P = Specifi
