P1504BVGN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID15m @VGS = 10V40V 9ASOP-8ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVGSGate-Source Voltage 20 VTA = 25 C9IDContinuous Drain CurrentTA = 70 C7.5AIDM35Pulsed Drain Current1IASAvalanche Current 32EASAvalanche Energy L = 0.1mH 52 mJTA= 25 C2.5PDPower Dissipation WTA =70 C1.6Tj, TstgOperating Junction & Storage Temperature Range -55 to 150 CTHERMAL RESISTANCE RATINGSTHERMAL RESISTANCE SYMBOL TYPICAL MAXIMUM UNITSJunction-to-Case RqJC 25C / WJunction-to-Ambient RqJA 501Pulse width limited by maximum junction temperature.REV 1.0 1 2014/9/19P1504BVGN-Channel Enhancement Mode MOSFETELECTRICAL CHARACTERISTICS (TJ = 25 C, Unless Otherwise Not
