Philips Semiconductors Product specification PowerMOS transistors PHP13N40E, PHB13N40E, PHW13N40E Avalanche energy ratedFEATURES SYMBOL QUICK REFERENCE DATAd Repetitive Avalanche Rated Fast switching VDSS = 400 V Stable off-state characteristics High thermal cycling performance ID = 13.7 Ag Low thermal resistanceRDS(ON) 0.35 sGENERAL DESCRIPTIONN-channel, enhancement mode field-effect power transistor, intended for use in off-line switched mode power supplies,T.V. and computer monitor power supplies, d.c. to d.c. converters, motor control circuits and general purpose switchingapplications.The PHP13N40E is supplied in the SOT78 (TO220AB) conventional leaded package.The PHW13N40E is supplied in the SOT429 (TO247) conventional leaded package.The PHB13N40E is supplied in the SOT404 surface mounting package.PINNING SOT78 (TO220
