PMBT3904M40 V, 200 mA NPN switching transistorRev. 01 21 July 2009 Product data sheetBOTTOM VIEW1. Product profile1.1 General descriptionNPN single switching transistor in a SOT883 (SC-101) leadless ultra smallSurface-Mounted Device (SMD) plastic package.PNP complement: PMBT3906M.1.2 Features Single general-purpose switching transistor Board-space reduction Ultra small SMD plastic package1.3 Applications General-purpose switching and amplification1.4 Quick reference dataTable 1. Quick reference dataSymbol Parameter Conditions Min Typ Max UnitVCEO collector-emitter voltage open base - - 40 VIC collector current - - 200 mAhFE DC current gain VCE =1V; 100 180 300IC =10mA2. Pinning informationTable 2. PinningPin Description Simplified outline Graphic symbol1 base312 emitter323 collector1Transparenttop view2sym021
