Preliminary Datasheet RJH60F5DPK R07DS0055EJ0300Silicon N Channel IGBT Rev.3.00High Speed Power Switching Nov 24, 2010Features Low collector to emitter saturation voltage VCE(sat) = 1.37 V typ. (IC = 40 A, VGE = 15 V, Ta = 25C) Built in fast recovery diode in one package Trench gate and thin wafer technology High speed switching tr = 85 ns typ. (at IC = 30 A, VCE = 400 V, VGE = 15 V, Rg = 5 , Ta = 25C, inductive load) Outline RENESAS Package code: PRSS0004ZE-A(Package name: TO-3P)C41. Gate2. CollectorG3. Emitter4. Collector (Flange)123EAbsolute Maximum Ratings (Tc = 25C) Item Symbol Ratings UnitCollector to emitter voltage VCES 600 VGate to emitter voltage VGES 30 VCollector current Tc = 25 C IC 80 ATc = 100 C IC 40 ACollector peak current ic(peak) Note1 160 ACollector to emitter di
