Preliminary Datasheet RJP60F5DPM R07DS0587EJ0100600 V - 40 A - IGBT Rev.1.00High Speed Power Switching Nov 25, 2011Features Low collector to emitter saturation voltage VCE(sat) = 1.37 V typ. (IC = 40 A, VGE = 15 V, Ta = 25C) Trench gate and thin wafer technology High speed switching Outline RENESAS Package code: PRSS0003ZA-A(Package name: TO-3PFM)C1. GateG 2. Collector3. EmitterE123Absolute Maximum Ratings (Tc = 25C) Item Symbol Ratings UnitCollector to emitter voltage VCES 600 VGate to emitter voltage VGES 30 VCollector current Tc = 25 C IC 80 ATc = 100 C IC 40 ACollector peak current ic(peak) Note1 160 ACollector dissipation PC 45 WJunction to case thermal impedance j-c 2.78 C/WJunction temperature Tj 150 C Storage temperature Tstg 55 to +150 C Notes: 1. Pulse width limited by sa
