S85N16R/S/RN/RP SI-TECH SEMICONDUCTOR CO.,LTD N-Channel Power MOSFETFeatures Applications VDS=85V,ID=153A DC Motor Control Rds(on)(typ)=4.6m@Vgs=10V DC-DC Converters 100% Avalanche Tested BMS 100% Rg Tested SMPS Lead-Free (RoHS Compliant) Automotive Environment Internal Circuit and Pin Description DDGG G GG D DD SS SSSPackage TO-220 TO-263 TO-220N TO-220P Package Code R S RN RP Package Marking Company Part No. and Package Code Assembly Information Lot No. Absolute Maximum Ratings(TC=25 unless otherwise noted) Symbol Parameter Value Units VDSS Drain-Source Voltage 85 V Continuous Drain Current (TC=25) 153 A ID Continuous Drain Current (TC=100) 96 A IDM Pulsed Drain Current (Note 1) 612 A VGS Gate-Source Voltage 20 VEAS Single Pulsed Avalanche Energy (N
