Product specification NPN Silicon Epitaxial Planar Transistor S9013 FEATURES Pb High Collector Current.(I = 500mA). CLead-free Complementary To S9012. Excellent H Linearity. FE Power dissipation.(P =300mW). CAPPLICATIONS High Collector Current. SOT-23 ORDERING INFORMATION Type No. Marking Package Code S9013 J3 SOT-23 : none is for Lead Free package; G is for Halogen Free package. MAXIMUM RATING @ Ta=25 unless otherwise specified Symbol Parameter Value Units Collector-Base Voltage V 40 V CBO Collector-Emitter Voltage V 25 V CEO Emitter-Base Voltage V 5 V EBO Collector Current -Continuous I 500 mA C Collector Dissipation P 300 mW C Junction and Storage Temperature T T -55 to +150 j, stg STM0147A www.gmesemi.com 1 Product specification NPN Silicon Epitaxial P
