S901 3TRANSISTOR(NPN) SOT-23 FEATURES 1. BASE Complementary to S9012 2. EMITTER Excellent hFE linearity 3. COLLECTOR MARKING: J3 MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value UnitsVCBO 40 VCollector-Base Voltage VCEO 25 VCollector-Emitter Voltage VEBO Emitter-Base Voltage 5 VIC Collector Current -Continuous 500 mA PC Collector Power Dissipation 300 mW Tj Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNIT Collector-base breakdown voltage V(BR)CBO 40 VIC= 100A, IE=0 Collector-emitter breakdown voltage V(BR)CEO 25 VIC= 0.1mA, IB=0 Emitter-base breakdown voltage V(BR)EBO 5 VIE=100A, IC=0 A Collector cut-off current ICBO VCB=40V, IE=0 0.1A Emitter cut-off curren
