Shenzhen Tuofeng Semiconductor Technology Co., Ltd TO-92 Plastic-Encapsulate Transistors S9013 TRANSISTOR (NPN) TO-92 FEATURE Complementary to S9012 1. EMITTER Excellent hFE linearity 2. BASE MAXIMUM RATINGS TA=25 unless otherwise noted 3. COLLECTOR Symbol Parameter Value Units VCBO Collector-Base Voltage 40 V VCEO Collector-Emitter Voltage 25 V VEBO Emitter-Base Voltage 5 VIC Collector Current -Continuous 500 mA PC Collector Dissipation 625 mW TJ Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNITCollector-base breakdown voltage V(BR)CBO IC= 100A , IE=0 40 VCollector-emitter breakdown voltage V(BR)CEO IC= 1mA , IB=0 25 VEmitter-base breakdown voltage V(BR)EBO IE= 100A , IC=0 5 VA Colle
