RoHS RoHSCOMPLIANT COMPLIANTS9013 NPN Transistor Features Epoxy meets UL-94 V-0 flammability rating Halogen free available upon request by adding suffix HF Moisture Sensitivity Level 1 Marking: J3 Maximum Ratings (Ta=25 unless otherwise noted) Item Symbol Unit Conditions Value Collector-Base Voltage VCBO V 40 Collector-Emitter Voltage VCEO V 25 Emitter-Base Voltage VEBO V 5Collector Current IC mA 500 Collector Power Dissipation PC mW 300 Thermal Resistance From Junction To Ambient RJA /W 416 Operation Junction Temperature Tj 150 Storage Temperature Tstg -55 to +150 Electrical Characteristics (Ta=25 unless otherwise noted) Item Symbol Unit Conditions Min Typ Max Collector-base breakdown voltage VCBO V IC=0.1mA,IE=0 40 Collector-emitter breakdown voltage VCEO* V IC =1mA,IB=0 25 Emitter-
