Shenzhen Tuofeng Semiconductor Technology Co., Ltd SOT-23 Plastic-Encapsulate Transistors SOT-23 S9013LT1 TRANSISTOR (NPN) 1. BASE FEATURES 2. EMITTER 3. COLLECTOR Complementary to S9012 Excellent hFE linearity MARKING: J3 MAXIMUM RATINGS (TA=25 unless otherwise noted) Symbol Parameter Value UnitsVCBO 40 VCollector-Base Voltage VCEO 25 VCollector-Emitter Voltage VEBO Emitter-Base Voltage 5 VIC Collector Current -Continuous 500 mA PC Collector Power Dissipation 300 mW Tj Junction Temperature 150 Tstg Storage Temperature -55-150 ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified) Parameter Symbol Test conditions MIN TYP MAX UNIT Collector-base breakdown voltage V(BR)CBO 40 VIC= 100A, IE=0 Collector-emitter breakdown voltage V(BR)CEO 25 VIC= 0.1mA, IB=0 Emitter-base breakdown voltage V(BR)EBO 5 VI
