SBT2222A NPN Silicon Transistor Descriptions General purpose application Switching application COLLECTOR33Features 1 Low Leakage current BASE Low collector saturation voltage enabling low voltage operation 2 Complementary pair with SBT2907A EMITTERSOT-23 Ordering Information Part Number Marking * Package 1P SBT2222A SOT-23 * Device Code Year & Week Code Factory Management Code Absolute maximum ratings (Ta=25C) Characteristic Symbol Ratings Unit Collector-Base voltage VCBO 75 V Collector-Emitter voltage VCEO 40 V Emitter-Base voltage VEBO 5 V IC 0.6 A(DC) Collector current ICP* 1.2 A(Pulse) Collector dissipation PC** 350 mW Operating Junction temperature range TJ -55~150 C Storage temperature range Tstg -55~150 C * : Single pulse, tp= 300 ** : Pac
