SiHG25N40Dwww.vishay.comVishay SiliconixD Series Power MOSFETFEATURESPRODUCT SUMMARY Halogen-free According to IEC 61249-2-21VDS (V) at TJ max. 450DefinitionRDS(on) max. at 25 C () VGS = 10 V 0.17 Optimal DesignQg max. (nC) 88- Low Area Specific On-ResistanceQgs (nC) 12- Low Input Capacitance (Ciss)Qgd (nC) 23- Reduced Capacitive Switching LossesConfiguration Single- High Body Diode Ruggedness- Avalanche Energy Rated (UIS)D Optimal Efficiency and OperationTO-247AC- Low Cost- Simple Gate Drive Circuitry- Low Figure-of-Merit (FOM): Ron x QgG- Fast Switching Compliant to RoHS Directive 2011/65/EUSDAPPLICATIONSGS Consumer ElectronicsN-Channel MOSFET - Displays (LCD or Plasma TV) Lighting Industrial- Welding- Induction Heating- Motor Drives- Battery Chargers SMPSORDERING INFOR
