SiHG25N50Ewww.vishay.comVishay SiliconixE Series Power MOSFETFEATURESPRODUCT SUMMARY Low figure-of-merit (FOM): Ron x QgVDS (V) at TJ max. 550 Low input capacitance (Ciss)RDS(on) max. at 25 C () VGS = 10 V 0.145 Reduced switching and conduction lossesQg (Max.) (nC) 86 Low gate charge (Qg)Qgs (nC) 14Qgd (nC) 25 Avalanche energy rated (UIS)Configuration Single Material categorization: for definitions of compliance please see www.vishay.com/doc?99912 DTO-247AC APPLICATONS Hard switched topologies Power factor correction power supplies (PFC)G Switch mode power supplies (SMPS) ComputingSD- PC silver box / ATX power suppliesSG LightingN-Channel MOSFET - Two stage LED lightingORDERING INFORMATIONPackage TO-247ACLead (Pb)-free and Halogen-free SiHG25N50E-GE3ABSOLUTE MAXIMUM RATINGS (
